UPN U CHANNEL STEEL

  • Main Grades: S355J2+AR,S355J2+N,S355J0+AR,S355J0+N,S235JR,S235J0+AR
  • Steel Standard: EN10025,GB/T707,DIN1025,EN BS4-1,EN10034,EN 10279,JIS G3192
  • Length: 1000mm-12000mm
  • Specification (mm): UPN40,UPN50,UPN60,UPN100,UPN120,UPN140,UPN160,UPN180,UPN200,UPN220
  • Surface treatment: Black,Hot dip galvanized,Primer painting,shot blasting
(※ Click this button to inquiry)
■ Overview
European steel specification UPN,U channel steel,upn steel channel are mainly used for general structural purposes.Dimensions contain UPN 100,UPN 120,UPN 140,UPN 160,UPN 200,UPN 220,UPN 240,UPN 260,UPN 300.UPN is U channel steel with tapered flanges and UPE is C channel steel with parallel flanges.
■ Full Data
  Additional Technical Services for UPN:
♦ Chemical composition and Mechanical properties test
♦ Lower temperature impacting test as per customers’demands
♦ Issued Orginal Mill test certificate under type EN 10204 FORMAT 3.1/3.2
♦ Packing with wooden case,pallets,bundled with iron belts.
♦ Dimensions for UPN Channel steel UPN 30 U30*33*5*7 UPN 40*20 U40*20*5*5.5
   UPN 40 U40*35*5*3.5 UPN 50 U50*38*5*7 UPN 65 U65*42*5.5*7.5
   UPN 80 U80*45*6*8 UPN 100 U100*50*6*8.5 UPN 120 U120*55*7*9
   UPN 140 U140*60*7*10 UPN 160 U160*65*7.5*10.5 UPN 180 180*70*8*11
   UPN 200 U200*75*8.5*11.5 UPN 220 U240*85*9.5*13 UPN 240 U240*85*9.5*13
   UPN 260 U260*90*10*14 UPN 280 U280*95*10*15 UPN 300 U300*100*10*16
   UPN 320 U320*100*14*17.5 UPN 350 U350*100*14*16 UPN 380 U380*102*13.5*16
   UPN 400 U400*110*14*18
■ Grades
All Steel Grades Chart for UPN channel steel:

MATERIAL STEEL GRADE
Low temperature UPN S235J0,S235J0+AR,S235J0+N,S235J2,S235J2+AR,S235J2+N,S355J2+M,
S355J0,S355J0+AR,S355J0+M,S355J2,S355J2+AR,S355J2+N,A283 Grade D
S355K2,S355NL,S355N,S275NL,S275N,S420N,S420NL,S460NL,S355ML
Q345C,Q345D,Q345E,Q355C,Q355D,Q355E,Q355F,Q235C,Q235D,Q235E
Mild steel UPN Q235B,Q345B,S355JR,S235JR,A36,SS400,A283 Grade C,St37-2,St52-3,
A992,A572 Grade 50,A633 Grade A/B/C,A709 Grade 36/50
